Product Type：Intelligent Hardware
The PLC Double Lamp Terminal Controller is a power line carrier (PLC) communication smart street lamp energy-saving product, which can provide remote switching, dimming and power collection functions for LED dimming constant current source drivers or dimmable electronic ballasts.
-PLC communication mode.
-1 controller for 2pcs LED street light
-AC input 86-305V, 50/60 Hz, switch capacity max. 16 A
-Dual Output
-Dual Dimming: 0-10V or PWM or DALI
-Operating conditions: -40°C to +85°C, 20% to 90% Rh non-condensing; IP65
-Product size(L*W*H): 189*73*50mm
Optional function:
1. Real time clock
